User Manual
Operation Instructions
Subject to modifications
2.1A-30008-A04
LINCOLN GmbH & Co. KG • Postfach 1263 • D-69183 Walldorf • Tel +49 (6227) 33-0 • Fax +49 (6227) 33-259
All rights reserved.
Any duplication of this User Manual, in its entirety or in part,
by whatever means is prohibited without the prior consent in
writing of Lincoln GmbH & CO. KG.
Subject to modifications without prior notification.
2004 by
LINCOLN GmbH & Co. KG
Postfach 1263
-69183 Walldorf
Phone: +49 (6227) 33-0
Fax: +49 (6227) 33-259
Fields of Application for Quicklub Progressive Central Lubrication Pumps
Industry - Machines Pump Type
Pump:
Reservoir:
Control:
Quicklub 223, 233
2 l - 2XL
1)
, 2XLBO
1)
4 l - 4XLBO
1)
8 l - 8XLBO
1)
1)
Filling from the bottom
4l, 8l – with lockable reservoir lid (Option)
Low-level control for all reservoir sizes
Integrated control unit with metering device
monitoring
See the respective model designation on the pump type plate e.g. P233-2XL-1K6-24-2A6.15-MDF00
or P223-2XL-1K6-24-2A6.15-MF00
Further information can be found in the following manuals:
Technical Description for „Diagnostic Software QuickData“ for pump 233 and QLS 331
Technical Description for progressive divider valves for grease and oil, model SSV, SSV M and SSV D
Installation Instructions
Parts Catalogue
Spare Parts Catalogue for pump 203
