Page 30 of 48
User Manual
Operation Instructions
Subject to modifications
2.1A-30008-A04
LINCOLN GmbH & Co. KG • Postfach 1263 • D-69183 Walldorf • Tel +49 (6227) 33-0 • Fax +49 (6227) 33-259
Setting and Operation, continuation
Operating Mode, continuation
4225a99
after two sec.
5 . (hours)
4226a99
after two sec.
. 10 (minutes)
4277a00
after two sec.
AC number of the automatically triggered lube cycles,
countable up to 9999 cycles.
Then counting starts from the beginning again.
Example 0625 cycles:
4281a00
after two sec.
06. Display for thousands and hundreds
06 as 600
4280a00
after two sec.
.25 Display for tens and ones
4278a00
after two sec.
4297a00
after two sec.
UC Number of the manually triggered
(by the user) additional lube cycles,
countable up to 9999 cycles.
Then counting starts from the beginning again.
Example 0110 cycles:
01. Display for thousands and hundreds
01 as 100
4226a99
after two sec.
Fig. 43 Operating mode (continuation next page)
.10 Display for tens and ones
