Issue 2.0
SV9100 Networking Manual 4-25
26-02-02 Dial Analysis Table for ARS – ARS Service
Type
For each Dial Analysis Table used (1~2000),
select Service Type 2 – F-Route Selected to
have the dialed number controlled by the F-
Route
table. If Service Type 2 is selected and
F-Route operation is on, the F-Route table used
is determined by Program 44-04.
0 = No Service (Call Restricted)
1 = Route to Trunk Group
2 = Select F-Route Access
Default = 0
26-02-03 Dial Analysis Table for ARS – Additional
Data
For each Dial Analysis Table (1~2000), enter
the F-Route table to use (1~500)
F-Route Table 0~500 Default = 0
26-02-04 Dial Analysis Table for ARS – ARS Class of
Service
For each Dial Analysis Table (1 ~ 2000), set the
Automatic Route Selection (ARS) Class of
Service (0 ~ 50).
Class = 0 ~ 50 Default = 0
26-03-01 ARS Dial Treatments – Treatment Code
For the originating system a treatment code
must be used for any route that will use
outbound trunks in a remote system.
The recommended treatment code is D019RE
where 9 is the trunk access code in the
destination system.
Maximum of 24 characters Default = Blank
26-04-01 ARS Class of Service
Set class of service for ARS. Used when 26-01-
07 is set to ARS.
Class = 0 ~ 50 Default = 0
34-02-01 E&M Tie Line Class of Service
This program can be used to assign the Tie
Line Class of Service (1 ~ 15) for inbound
trunks.
Use Program 20-14-01 to set the Tie Line Class
of Service options. You cannot use Program 20-
06 to assign Class of Service to Tie Lines.
Day/Night Mode
1 ~ 8
Class: 1 ~ 15
Default = 1
44-02-01 Dial Analysis Table for ARS/F-Route Access
– Dial
Set the Dial digits for the Pre-Transaction Table
for selecting ARS/F-Route (eight digits
maximum: 1 ~ 9, 0, #, @). To enter a wild card/
don’t care digit, press Line Key 1 to enter an @
symbol.
Up to eight digits max. Default = No
Setting
44-02-02 Dial Analysis Table for ARS/F-Route Access
– Service Type
Set the Service Type (0 ~ 3) for the
Pre-Transaction Table for selecting ARS/
F-Route.
0 = No Setting (None)
1 = Extension Call (Own)
2 = ARS/F-Route Table
(F-Route)
3 = Dial Extension Analyze
Table (Option)
Default = 0
Program
Number
Program Name/Description Input Data Default
