Issue 2.0
SV9100 Networking Manual 4-7
Description
Use Program 10-03 : ETU Setup to setup and confirm the Basic Configuration data
for each blade. When changing a defined terminal type, first set the type to 0 and
then plug the new device in to have the system automatically define it or you may
have to reseat the blade.
Input Data
For CNF PKG Setup
For DLCA PKG Setup
Program 10 : System Configuration Setup
10-03 : ETU Setup
Level:
IN
The items highlighted in gray are read only and cannot be changed.
Physical Port Number 01~16
Item
No.
Item Input Data Default
01
Logical Port Number
0~960 0
Physical Port Number 01~16
Item
No.
Item Input Data Default
01
Terminal Type (B1)
0 = Not set
1 = Multiline Terminal
3 = Bluetooth Cordless Handset
6 = PGD(2)-U13 (Paging)
7 = PGD(2)-U13 (Tone Ringer)
8 = PGD(2)-U13 (Door Box)
9 = PGD(2)-U13 (ACI)
10 = DSS Console
11 = -- Not Used ---
0
