NEC Univerge SV9100 - Page 272

Issue 2.0
4-8 Programming
02
Logical Port Number
(B1)
0 = Not set
1 = Multiline Terminal (1~960)
6 = PGD(2)-U13 (Paging) (1~8)
7 = PGD(2)-U13 (for Tone Ringer)
(1~8)
8 = PGD(2)-U13 (for Door Box) (1~8)
9 = PGD(2)-U13 (for ACI) (1~96)
10 = DSS (1~32)
11 = --- Not Used ---
0
03
--- Not Used ---
B-Channel 2
Item
No.
Item Input Data Default
06
Terminal Type (B2)
0 = Not set
6 = PGD(2)-U13 (Paging)
7 = PGD(2)-U13 (Tone Ringer)
8 = PGD(2)-U13 (Door Box)
9 = PGD(2)-U13 (ACI)
12 = APR(B2 Mode)
0
07
Logical Port Number (B2)
0 = Not set
6 = PGD(2)-U13 (Ext. Speaker)
7 = PGD(2)-U13 (Paging/Tone Ringer) (1~8)
8 = PGD(2)-U13 (for Door Box) = (1~8)
9 = PGD(2)-U13 (ACI) = (1~96)
12 = APR (for B2 mode) (193~512)
0
08
Multiline Telephone Type
0 = DT3**
1 = DT4**
0
09
Side Option Information
0 = No option
1 = 8LK Unit
2 = 16LK Unit
3 = 24ADM
0
10
Bottom Option
Information (Only applies
to DTL style telephones)
0 = No option
1 = APR
2 = ADA
3 = BHA
4 = Not Used
5 = BCA
0
Item
No.
Item Input Data Default
