Issue 2.0
4-16 Programming
For IPLE PKG Setup
For VM00 PKG Setup
For CCTA PKG Setup
Physical Port Number 001~256
Item
No.
Item Input Data Default
01
VOIP Type
0 = Not Used
1 = Not Used
2 = Not Used
3 = IPLE
None (will be
determined
when
Installed)
02
Number of Channels
0 ~ 256 (Read Only)
0
03
Number of Voice Channels
0 ~ 256 (Read Only)
0
Physical Port Number 01~16
Item
No.
Item Input Data Default
01
Logical Port Number
0~480
0
Physical Port Number 01~24
Item
No.
Item Input Data Default
01
Logical Port Number
The start port number of a T1 line is
displayed, and 24 logic ports are
automatically assigned to a DTI (T1)
line.
0~400
0
02
T1 Signal Format Selection
0 = D4 (12 Multi Frame)
1 = ESF (24 Multi Frame)
1
03
Zero Code Suppression
0 = B8ZS
1 = AMI/ZCS
0
04
Line Length Selection
0 = 0 feet ~ 133 feet
1 = 133 feet ~ 266 feet
2 = 266 feet ~ 399 feet
3 = 399 feet ~ 533 feet
4 = 533 feet ~ 655 feet
0
05
T1 Clock Source
0 = Internal
1 = External
1
To Next Page
