Issue 2.0

SV9100 Networking Manual 4-25

Description

Use Program 10-15 : Client Information Setup to set up the client information

when the DHCP server needs to assign a fixed IP address to clients.

Conditions

None

Feature Cross Reference

 Voice Over Internet Protocol (VoIP)

Program 10 : System Configuration Setup

10-15 : Client Information Setup

Level:

Input Data

Client Number 1~960

Item

No.

Item Input Data Default

The IP address should be

assigned out of the scope

range set up in Program 10-

14.

MAC: 00-00-00-00-00-00 ~

FF-FF-FF-FF-FF-FF

00-00-00-00-00-00

1.0.0.0 ~ 126.255.255.254

128.0.0.1 ~ 191.255.255.254

192.0.0.1 ~ 223.255.255.254

0.0.0.0
