NEC Univerge SV9100

To Next Page

To Previous Page

Issue 2.0

6-6 SIP Trunking

Default Settings

Disabled

System Availability

Terminals

All Multiline Terminals

Trunks

IP SIP

Required Component(s)

 GCD-CP10

 GPZ-IPLE

 R2 Enhancement License (0412)

 System Port License (0300)

 VoIP Resource License (5103)

 IP Trunk License (5001)

SECTION 4 VIDEO SUPPORT OVER SIP TRUNKS

Description

The SV9100 can support video calling over SIP interconnection trunks. The IP Trunk

license (5001/5103), IP Station licenses (5111), R2 Enhancement license (0412) and

Video MCU license (0042) are required.

Conditions

 Calls over SIP Interconnection while in P2P mode cannot be put on

hold.

 Calls over SIP Interconnection while in P2P mode cannot be

transferred, i.e. an internal call cannot be transferred to a SIP

Interconnection trunk.

 A video call cannot be changed to a voice call. A voice call cannot be
