SV9100 Networking Manual 9-11

10-58-02 Network Address –

Subnet Mask

This program sets the

netmask for the IP Addresses

assigned in Program 10-58-

01.

128.0.0.0 / 192.0.0.0

224.0.0.0 / 240.0.0.0

248.0.0.0 / 252.0.0.0

254.0.0.0 / 255.0.0.0

255.128.0.0

255.192.0.0

255.224.0.0

255.240.0.0

255.248.0.0

255.252.0.0

255.254.0.0

255.255.0.0

255.255.128.0

255.255.192.0

255.255.224.0

255.255.240.0

255.255.248.0

255.255.252.0

255.255.254.0

255.255.255.0

255.255.255.128

255.255.255.192

255.255.255.224

255.255.255.240

255.255.255.248

255.255.255.252

255.255.255.254

255.255.255.255

(default =

255.255.0.0)

15-05-16 IP Telephone Terminal

Basic Data Setup –

Authentication

Password

Assign the authentication

password for SIP single line

telephones.

Up to 24 characters

(default not assigned)

Program

Number

Program Name Description/Comments Assigned Data 1 2 3
