NEC Univerge SV9100

To Next Page

To Previous Page

Issue 2.0

SV9100 Networking Manual 10-59

Conditions

 The system must be reset for these changes to take affect.

Feature Cross Reference

 Voice Over Internet Protocol (VoIP)

NIC Setup

0 = Auto Detect

1 = 100Mbps, Full-Duplex

3 = 10Mbps, Full-Duplex

5 = 1 Gbps, Full-Duplex

Set for IPLE.

Input Data (Continued)
