Issue 2.0

10-78 SV9100 NetLink

Description

Use Program 51-15: Demonstration Setting to automatically set the minimum

setting values in NetLink. A system reset occurs after this command is executed..

Conditions

None

Feature Cross Reference

None

Program 51 : NetLink Service

51-15 : Demonstration Setting

Level:

NOTE



This program is available only via telephone programming and not through PC

Programming.

Input Data

Menu Number

1 = Primary automatic setting

2 = Secondary 1 - automatic operation setting

3 = Secondary 2 - automatic operation setting

4 = Secondary 3 - automatic operation setting
