Issue 2.0
SV9100 Networking Manual 10-79
Description
Use Program 51-16: NetLink System Data Replication Mode Setting to set the
system data replication between the Primary and Secondary systems.
.
Program 51 : NetLink Service
51-16 : NetLink System Data Replication Mode Setting
Level:
IN
Input Data
Item
No.
Item Input Data Default
01
System Data Replication Mode
Set the synchronous mode of the system data.
When set to 1, the systems are synchronized at
the time set in Item 02 below.
When set to 2, the systems are synchronized at
regular time intervals set in Item 03 below.
0 = Disable
1 = Setting Time Mode
2 = Interval Mode
0
02
System Data Replication Time Setting
Set the time of day that both systems
synchronize database (when Item 01 is set to 1.)
0000~2359
0200
03
System Data Replication Interval Setting
Set the time interval that both systems
synchronize database (when Item 01 is set to 2).
15~1440 (minutes)
30 (min)
04
Replication Time Stamp
Show next replication time. (Read-Only)
Month: 0~12
–
Day: 0~31
–
Hour: 00~23
–
Minute: 00~59
–
05
System Data Replication Wait Time
Set the wait time until replication starts when
NetLink is created.
1~86400 (seconds)
180 sec
06
System Data Replication Interval
Set time to start replication to the next node after
replication to one node is completed.
0~86400 (seconds)
1 sec
IMPORTANT
In a NetLink system with In-Mail, replication should be scheduled during
non-peak hours of operation
