Issue 2.0
11-14 NAPT
 It is assumed that port numbers are not changed by the NAT router on the terminal
side. If a port number is changed by NAT router, NEC does not guarantee proper
operation.
 If installing multiple terminals in the domain of the NAT router on the terminal side,
the SIP port number and RTP/RTCP port number for each terminal must be
specified so as to avoid overlapping.
 The SIP server cannot be switched. (Only one address can be registered as the SIP
server.).
 NetLink Failover is not supported.
SECTION 4 MINIMUM REQUIRED PROGRAMMING
The Level 1, Level 2 and Level 3 columns indicate the programs that are assigned
when programming this feature in the order they are most commonly used. These
levels are used with PCPro and WebPro wizards for feature programming.
 Level 1 – these are the most commonly assigned programs for this feature.
 Level 2 – these are the next most commonly assigned programs for this feature.
 Level 3 – these programs are not often assigned and require an expert level
working knowledge of the system to be properly assigned.
Program
Number
Program Name Description/Comments Assigned Data
Level
1 2 3
10-12-01 GCD-CP10 Network Setup –
IP Address
Assign the IP Address for the CPU
NIC card. When a IPLE card is
installed in the system it is
recommended to set this PRG to
0.0.0.0
0.0.0.0 ~
126.255.255.254
128.0.0.1 ~
191.254.255.254
192.0.0.1 ~
223.255.255.254
(default = 172.16.0.10

10-12-03 GCD-CP10 Network Setup –
Default Gateway
Assign the default gateway IP
address for the GCD-CP10.
0.0.0.0 ~
126.255.255.254
128.0.0.1 ~
191.254.255.254
192.0.0.1 ~
223.255.255.254
(default = 0.0.0.0)

10-12-07 GCD-CP10 Network Setup –
NAPT Router IP Address
(Default Gateway [WAN])
Define the IP Address of the WAN
side of the router.
0.0.0.0 ~
126.255.255.254
128.0.0.1 ~
191.255.255.254
192.0.0.1 ~
223.255.255.254
(default = 0.0.0.0)

