Issue 2.0
11-18 NAPT
15-05-47 Registration Expire Timer for
NAPT
On a per station basis, this setting
defines the SIP registration expiry
timer. This setting only applies to
DT800/DT700 stations connected
via NAPT. If this value is set to 0,
for a NAPT terminal, the value in
PRG 84-23-01 is applied.
0 = Disable
1 = 60 - 65535 (sec)
(default - 180)

15-05-48 Subscribe Expire Timer for
NAPT
On a per station basis, this setting
defines the SIP subscribe expiry
timer. This setting only applies to
DT800/DT700 stations connected
via NAPT. If this value is set to 0,
for a NAPT terminal, the value in
PRG 84-23-02 is applied.
0 = Disable
1 = 60 - 65535 (sec)
(default - 180)

84-26-01 IPL Basic Setup – IP Address When using a GPZ-IPLE assign
only one IP address.
Slot 1 = 172.16.0.20

84-26-02 IPL Basic Setup – RTP Port
Number
Assign the RTP port number to be
used for each DSP on the IPLE.
 Only even numbered ports
are supported.
VoIP GW1 = 10020

84-26-03 IPL Basic Setup – RTCP Port
Number (RTP Port Number + 1)
Define the TCP port number for
RTCP to use for each DSP.
VoIP GW1 = 10021

Program
Number
Program Name Description/Comments Assigned Data
Level
1 2 3
