10-58-02 Network Address - Subnet Mask This program sets the local area
network of the DT800/DT700
terminal
when the system has a NAT router
and a local router.
248.0.0.0 / 252.0.0.0 /
254.0.0.0 / 255.0.0.0
255.128.0.0 /
255.192.0.0 /
255.224.0.0
255.240.0.0 /
255.248.0.0 /
255.252.0.0
255.254.0.0 /
255.255.0.0 /
255.255.128.0
255.255.192.0 /
255.255.224.0
255.255.240.0 /
255.255.248.0
255.255.252.0 /
255.255.254.0
255.255.255.0 /
255.255.255.128
255.255.255.192 /
255.255.255.224
255.255.255.240 /
255.255.255.248
255.255.255.252 /
255.255.255.254

15-05-45 IP Telephone Terminal Basic
Data Setup - NAT Plug and Play
This Program is valid when
Program 10-46-14 is On (NAT
feature activated). Select sending
RTP port number to remote
Router, use from negotiation result
(0) or received RTP packet (1).
SV9100 uses this program to
decide a destination port of RTP
transmitting packets from IPLE to
a remote IP terminal. If “0:OFF” is
selected, the destination port of
RTP transmitting packets will be a
SIP/SDP negotiation result.(same
behavior as before). If you chose
“1:ON”, the destination port of RTP
transmitting packet will be the
same port of a source port of a
receiving RTP packet on IPLE.
0 = Disable (default)
1 = Enable

