Issue 2.0
13-64 AspireNet
For BRIA PKG Setup
ISDN Line Number 01~04
Item
No
Item Input Data Default
01
ISDN Line Mode
0 =No setting
1=T-Point
2=S-Point
3 =NW Mode (Leased Line)
4 =NW Mode (Interconnected Line)
5 =NW Mode (Interconnected Line,
Fixed Layer1=NT)
6 =S-Point (Leased Line)
1
02
Logical Port Number
 The starting port number of a BRI
line is displayed. Two logic ports are
automatically assigned to a BRI line.
[0:No setting] = 0
[1:T-Point] = 1-400
[2:S-Point] = 1-960
[3:NW Mode (Leased Line)] = 1-256
[4:NW Mode (Interconnected Line)]
= 1-256
[5:NW Mode (Interconnected Line,
Fixed Layer1=NT)] = 1-256
[6:S-Point(Leased Line)] = 1-960
0
03
Connection Type
0 =Point-to-Multipoint
1 =Point-to-Point
0
04
Layer 3 Timer Type
 Each timer value of Layer 3 is set up
for every type using Program 81-06
(T-Bus).
1~5
1
05
CLIP Information Announcement
Based on this setting, the system
includes a Presentation Allowed (1) or
Presentation Restricted (0) in the Setup
message to allow or deny the Calling
Party Number. Program 15-01-04 must
also be set to 1 if this option is enabled.
0 =Disable
1 =Enable
1
06
Connection Bus Mode
0 =Extended passive bus
1 =Short passive bus
0
07
S-point DDI digits
0 - 4
0
08
Dial Sending Mode
ISDN Protocol definition
0 =Enblock Sending
1 =Overlap Sending
1
09
Dial Information Element
ISDN Protocol definition
[Only when Dialing Sending Mode
(10-03-08) is set for 1 (Overlap Sending]
0 =Keypad Facility
1 =Called Party Number
0
