Issue 2.0

SV9100 Networking Manual 13-79

Conditions

The keep alive message must be sent and a response not received for the retry count, for the link to be taken

out of service and the calls in progress and Park Hold orbits to be released.

For example: If an ISDN Net Link connection is disconnected at Layer 1 then the keep alive message can not

be sent, therefore the keep alive operation will not occur.

Feature Cross Reference
