4-20 Features and Specifications
Programming Example
The following example will use the first two priorities of System A to route 10 digit
local calls out trunk group one of System B and if that fails the call is routed out trunk
group one of System A.
This example assumes the following:
System A has local trunks 1-8 in trunk group 1.
Both systems are already configured for the LAN on which they reside and
have a network route to each other.
Both systems are configured for K-CCISoIP.
System A is assigned point code 1 and 1XX extensions.
System B is assigned point code 2 and 2XX extensions.
While dial analysis can be configured in all systems, for this example only
System A has ARS dial analysis configured.
Table 4-1 Programming Example
Program Description
System A
Setting
System B
Setting
10-68-01 IP Trunk Mode CCIS
33
10-68-02 Starting CCIS Trunk Number
99
10-68-03 Number of CCIS Trunks to Create.
This will create CCISoIP trunks 9-
16.
88
14-05-01 First setting data. Put CCISoIP
trunks in trunk group 10.
10 10
14-05-01 Second setting data. Set priorities 1-
8 for trunks 9-16.
1~8 1~8
26-01-01 Enable ARS Services
11
26-02-01 For table entry 1 enter 5 wildcard
characters.
@@@@@ N/A
26-02-02 For table entry 1 set service type to
F-Route (2)
2N/A
26-02-03 For table entry 1 set additional data
to F-Route Table 2.
2N/A
26-03-01 Set ARS Treatment 1 to sent the
number including the trunk access
code of 9 to System B.
D019RE N/A
44-02-01 Closed numbering setup - Set to first
digit of remote system extension
number
21
To Next Page
