Introduction
16
NETGEAR ProSAFE VPN Firewall FVS318G v2
Rear Panel
The rear panel of the VPN firewall includes the antennas, a cable lock receptacle, a console
port, a Reset button, a DC power connection, and a power switch.
Figure 3. Back panel
Viewed from left to right, the rear panel contains the following components:
1. Cable security lock receptacle.
2.
Console port.
Port for connecting to an optional console terminal. The port provides a DB9
male connector. The default baud rate is 9600 K. The pinouts are (2) Tx, (3) Rx, (5) and (7)
Gnd.
3. Factory default Reset button.
Using a sharp object, press and hold this button for about
eight seconds until the front panel Test LED blinks. To reset the VPN firewall to factory
default settings. All configuration settings are lost, and the default password is restored.
4. DC power plug receptacle.
Power input is 12 VDC, 1A. The power plug is localized to the
country of sale.
(1) Security lock
receptacle
(2) Console port
(3) Reset button
(4) DC power
receptacle
