NETGEAR FVS318G User Manual

IPv4 and IPv6 Internet and Broadband Settings
40
NETGEAR ProSAFE VPN Firewall FVS318G v2
WARNING:
Changing the IP routing mode causes the VPN firewall to reboot.
4. Click the Apply button.
Your settings are saved.
Use a DHCPv6 Server to Configure an IPv6 Internet
Connection
The VPN firewall can autoconfigure its ISP settings through a DHCPv6 server by using either
stateless or stateful address autoconfiguration:
• Stateless address autoconfiguration. The
VPN firewall generates its own IP address
by using a combination of locally available information and router advertisements, but
receives DNS server information from a DHCPv6 server.
Router advertisements include a prefix that identifies the subnet that is associated
with
the WAN port. The IP address is formed by a combination of this prefix and the MAC
address of the WAN port. The IP address is a dynamic address.
As an option for stateless address autoconfiguration, the ISP’s st
a
teful DHCPv6 server
can assign a prefix through prefix delegation. The VPN firewall’s own stateless DHCPv6
server can assign this prefix to its IPv6 LAN clients. For more information about prefix
delegation, see Stateless DHCPv6 Server with Prefix Delegation on page
79.
• Stateful address autoconfiguration. Th
e VPN firewall obtains an interface address,
configuration information such as DNS server information, and other parameters from a
DHCPv6 server. The IP address is a dynamic address.
 To automatically configure the WAN port for an IPv6 connection to the Internet:
1. Log in to the unit:
a. In the address field of any of the qualified web browsers, enter
https://192.168.1.1.
The NETGEAR Configuration Manager Login screen displays.
b. In the User
name field, enter admin and in the Password / Passcode field, enter
password.
Use lowercase letters. If you changed the password, enter your persona
lized
password. Leave the domain as it is (geardomain).
c. Click
the L
ogin button.
The Router Status screen displays. After five minutes of inactivity,
which is the default
login time-out, you are automatically logged out.
2. Select Network Confi
guration > WAN Settings > Broadband ISP Settings.
The Broadband ISP Settings screen displays.

NETGEAR FVS318G Specifications

General

Power requirements	12V DC, 1.5A
Firewall throughput	250 Mbit/s
Maximum data transfer rate	1000 Mbit/s
HTTP performance	6000 transactions/sec
Wi-Fi	No
DHCP server	Yes
Number of VLANs	256
VPN tunnels quantity	12
WAN connection	Ethernet (RJ-45)
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	9
Ethernet DMZ ports quantity	1
Routing protocols	RIP-1, RIP-2
Supported network protocols	TCP/IP, UDP, ICMP, PPPoE
VPN support	IPsec (ESP), IKE, PKI, HTTPS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, MD5, SHA-1
Internal memory	128 MB
Flash memory	32 MB
Storage media type	Flash
Processor frequency	300 MHz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	590 g
Dimensions (WxDxH)	190 x 125 x 35 mm
