Firewall Protection
206
NETGEAR ProSAFE VPN Firewall FVS318G v2
The Router Status screen displays. After five minutes of inactivity, which is the default
login time-out, you are automatically logged out.
2. Select S
e
curity > Address Filter > IP/MAC Binding.
The IP/MAC Binding screen displays.
3. On the IP/MAC Bindings screen for IPv6, to the right of the IP/MAC Binding tab, click the Set
Poll
Interval option arrow.
4. Click the St
op button.
Wait until the Poll Interval field
becomes available.
5. Enter new poll interval in seconds.
6.
Click the Set
Interval button.
Wait for the confirmation that the operation succeeded before you clo
se the window.
Configure Port Triggering
Port triggering allows some applications running on a LAN network to be available to external
applications that would otherwise be partially blocked by the firewall. Using the port triggering
feature requires that you know the port numbers used by the application.
Note: Port triggering is supported for IPv4 devices only.
Once configured, port triggering operates as follows:
1. A computer makes an outgoing connection using a port number that
is defined in the
Port Triggering Rules table.
2. The VPN firewall records this connection, opens the additional incoming
port or ports that
are associated with the rule in the port triggering table and associates them with the
computer.
3. The remote system receives the computer
’s request and responds using the incoming port
or ports that are associated with the rule in the port triggering table on the VPN firewall.
4. The VPN firewall matches the response to the previous request and
forwards the response
to the computer.
