5. Virtual Private Networking Using
IPSec and L2TP Connections
This chapter describes how to use the IP security (IPSec) virtual private networking (VPN)
features of the VPN firewall to provide secure, encrypted communications between your local
network and a remote network or computer. The chapter contains the following sections:
• Use the IPSec VPN Wizard for Client and Gateway Configurations
• Test the Connection and View Connection and
S
tatus Information
• Manage IPSec VPN Policies
• Configure Extended Authentication (XAUTH)
• Assign IPv4 Addresses to Remote Users
• Configure Keep-Alives and Dead Peer Detection
• Configure NetBIOS Bridging with IPSec VPN
• Configure the L2TP Server

NETGEAR FVS318G Specifications

General

Power requirements	12V DC, 1.5A
Firewall throughput	250 Mbit/s
Maximum data transfer rate	1000 Mbit/s
HTTP performance	6000 transactions/sec
Wi-Fi	No
DHCP server	Yes
Number of VLANs	256
VPN tunnels quantity	12
WAN connection	Ethernet (RJ-45)
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	9
Ethernet DMZ ports quantity	1
Routing protocols	RIP-1, RIP-2
Supported network protocols	TCP/IP, UDP, ICMP, PPPoE
VPN support	IPsec (ESP), IKE, PKI, HTTPS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, MD5, SHA-1
Internal memory	128 MB
Flash memory	32 MB
Storage media type	Flash
Processor frequency	300 MHz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	590 g
Dimensions (WxDxH)	190 x 125 x 35 mm
