IPv4 and IPv6 Internet and Broadband Settings
31
NETGEAR ProSAFE VPN Firewall FVS318G v2
The Connection Status screen shows a valid IP address and gateway, and you are
connected to the Internet. If the configuration was not successful, skip ahead to Manually
Configure an IPv4 Internet Connection on pag
e 31, or see Troubleshoot the ISP
Connection on p
age 389.
Note: For more information about the Connection Status screen, see View
the WAN Port Status on page 373.
Manually Configure an IPv4 Internet Connection
Unless your ISP automatically assigns your configuration through a DHCP server, you must
obtain configuration parameters from your ISP to manually establish an Internet connection.
The required parameters for various connection types are listed in Table 2 on page 30.
To manually configure the IPv4 broadband ISP settings:
1. Log in to the unit:
a. In the address field of any of the qualified web browsers, enter
https://192.168.1.1.
The NETGEAR Configuration Manager Login screen d
isplays.
b. In the Username
field, enter admin and in the Password / Passcode field, enter
password.
Use lowercase letters. If you changed the password, enter your personalized
password. Leave the domain as it is (geardomain).
c. Click the Logi
n button.
The Router Status screen displays. After five minutes of inactivity
, which is the default
login time-out, you are automatically logged out.
2. Select Network Con
figuration > WAN Settings > Broadband ISP Settings.
In the upper right of the screen, the IPv4 radio butto
n is selected by default. The ISP
Broadband Settings screen displays the IPv4 settings.
3. Locate
the ISP Login section.
4. Select one of the following options:
• If your ISP requires an initial login to establish an Internet connection
, select the Yes
radio button. (The default is No.)
• If a login is not required, select the No radio
button, and ignore the Login and
Password fields.
