NETGEAR FVS318G User Manual

125
4
4. Firewall Protection
This chapter describes how to use the firewall features of the VPN firewall to protect your
network. The chapter contains the following sections:
• About Firewall Protection
• Overview of Rules to Block or Allow Specific Kinds of Traffic
• Co
nfigure LAN WAN Rules
• Configure DMZ WAN Rules
• Configure LAN DMZ Rules
• Examples of Firewall Rules
• Configure Other Firewall Features
• Services, Bandwidth Profiles, and QoS Profiles
• Configure Content Filtering
• Set a Schedule to Block or Allow Specific Traffic
• Enable Source MAC Filtering
• Set Up IP/MAC Bindings
• Configure Port Triggering
• Configure Universal Plug and Play

NETGEAR FVS318G Specifications

General

Power requirements	12V DC, 1.5A
Firewall throughput	250 Mbit/s
Maximum data transfer rate	1000 Mbit/s
HTTP performance	6000 transactions/sec
Wi-Fi	No
DHCP server	Yes
Number of VLANs	256
VPN tunnels quantity	12
WAN connection	Ethernet (RJ-45)
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	9
Ethernet DMZ ports quantity	1
Routing protocols	RIP-1, RIP-2
Supported network protocols	TCP/IP, UDP, ICMP, PPPoE
VPN support	IPsec (ESP), IKE, PKI, HTTPS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, MD5, SHA-1
Internal memory	128 MB
Flash memory	32 MB
Storage media type	Flash
Processor frequency	300 MHz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	590 g
Dimensions (WxDxH)	190 x 125 x 35 mm
