Virtual Private Networking Using IPSec and L2TP Connections
268
NETGEAR ProSAFE VPN Firewall FVS318G v2
10. Click the Apply button.
Your changes are saved.
Configure the ProSafe VPN Client for Mode Config Operation
When the Mode Config feature is enabled, the following information is negotiated between
the VPN client and the VPN firewall during the authentication phase:
• V
irtual IP address of the VPN client
• DNS server
address (optional)
• WINS server address (optional)
The virtu
al IP address that is issued by the VPN firewall is displayed in the VPN Client
Address field on the
VPN client’s IPSec pane.
Extended Authentication
XAUTH Configuration
Note: For more
information about
XAUTH and its
authentication modes,
see Configure XAUTH
for VPN Clients on
page 257.
Select whether Extended Authentication (XAUTH) is enabled, and, if enabled,
which device is used to verify user account information:
• None.
XAUTH is disabled. This the default setting.
• Edge Device.
The VPN firewall functions as a VPN concentrator on which one
or more gateway tunnels terminate. The authentication modes that are
available for this configuration are User Database, RADIUS PAP, and RADIUS
CHAP.
• IPSec
Host.
The VPN firewall functions as a VPN client of the remote
gateway. In this configuration, the VPN firewall is authenticated by a remote
gateway with a user name and password combination.
Authentication
Typ
e
For an Edge Device configuration, from the list, select the
authentication type:
• User Database.
XAUTH occurs through the VPN firewall’s
user database. You can add users on the Add User screen
(see User Database Configuration on page 259).
• Radius PAP.
XAUTH occurs through RADIUS Password
Authentication Protocol (PAP). The local user database is
first checked. If the user account is not present in the local
user database, the VPN firewall connects to a RADIUS
server. For more information, see RADIUS Client and
Server Configuration on
p
age 259.
• Radius CHAP. XAUTH occurs through RADIUS
Challenge Handshake Authentication Protocol (CHAP).
For more information, see RADIUS Client and Server
Configuration on
page 259.
Username The user name for XAUTH.
Password The password for XAUTH.
Table 57. Add IKE Policy screen settings for a Mode Config configuration (continued)
Setting Description
