NETGEAR FVS318G User Manual

LAN Configuration
88
NETGEAR ProSAFE VPN Firewall FVS318G v2
The information is deleted.
Configure the IPv6 Router Advertisement Daemon and
Advertisement Prefixes for the LAN
Note: If you do not configure stateful DHCPv6 for the LAN but use stateless
DHCPv6, you must configure the Router Advertisement Deamon
(RADVD) and advertisement prefixes.
The RADVD is an application that uses the Neighbor Discovery Protocol (NDP) to collect
link-local advertisements of IPv6 addresses and IPv6 prefixes in the LAN. The RADVD then
distributes this information in the LAN, which allows IPv6 clients to configure their own IPv6
address.
Hosts and routers in the LAN use NDP to determine the link-layer addresses and
related
information of neighbors in the LAN that can forward packets on their behalf. The VPN
firewall periodically distributes router advertisements (RAs) throughout the LAN to provide
such information to the hosts and routers in the LAN. RAs include IPv6 addresses, types of
prefixes, prefix addresses, prefix lifetimes, the maximum transmission unit (MTU), and so on.
In addition to configuring the RADVD, you also must configure the prefixes that are
advertised in the LAN RAs.
The following table provides an overview of how information is ob
t
ained in the LAN when you
configure a stateless DHCPv6 server and the RADVD:
When the Managed flag is set in the RADVD, the DHCPv6 server can assign IP addre
sses,
and the RADVD also assigns IP addresses in the sense that it provides information that
allows IPv6 clients to configure their own IPv6 address.
When the Other flag is set, the DHCPv6 server does not assign IP addresses but
p
rovides
DNS server and other configuration information only.
Table 15. DHCPv6 and RADVD interaction in the LAN
Flags in the RADVD DHCPv6 Server Provides RADVD Provides
Managed RA flag is set.
• IP address assignment
• DNS server and other configuration
information
• IP address assignment
• Prefix
• Pre
fix length
• Gateway
address
Other RA flag is set. DNS server and other configu
ration information • IP address assignment
• Prefix
• Prefix length
• Gateway
address

NETGEAR FVS318G Specifications

General

Power requirements	12V DC, 1.5A
Firewall throughput	250 Mbit/s
Maximum data transfer rate	1000 Mbit/s
HTTP performance	6000 transactions/sec
Wi-Fi	No
DHCP server	Yes
Number of VLANs	256
VPN tunnels quantity	12
WAN connection	Ethernet (RJ-45)
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	9
Ethernet DMZ ports quantity	1
Routing protocols	RIP-1, RIP-2
Supported network protocols	TCP/IP, UDP, ICMP, PPPoE
VPN support	IPsec (ESP), IKE, PKI, HTTPS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, MD5, SHA-1
Internal memory	128 MB
Flash memory	32 MB
Storage media type	Flash
Processor frequency	300 MHz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	590 g
Dimensions (WxDxH)	190 x 125 x 35 mm
