Virtual Private Networking Using IPSec and L2TP Connections
232
NETGEAR ProSAFE VPN Firewall FVS318G v2
This is the name for the IPSec configuration that is used only for the VPN client, not
during IPSec negotiation. You can view and change this name in the tree list pane. This
name must be a unique name.
4. Specify the settings that are described in the following table.
Table 48. VPN client IPSec configuration settings
Setting Description
VPN Client address Either enter 0.0.0.0 as the IP address, or enter a virtual IP address that the VPN
client uses in the VPN firewall’s LAN; the computer (for which the VPN client
opened a tunnel) appears in the LAN with this IP address.
Address Type Select Subnet address from the list. This selection defines which addresses the
VPN client can communicate with after the VPN tunnel is established.
Remote LAN address Enter 192.168.1.0 as the remote IP address (that is, LAN network address) of the
gateway that opens the VPN tunnel.
Subnet mask Enter 255.255.255.0 as the remote subnet mask of the gateway that opens the VPN
tunnel.
ESP Encryption Select 3DES as the encryption algorithm from the list.
Authentication Select SHA-1 as the authentication algorithm. from the list
Mode Select Tunnel as the encapsulation mode from the list.
PFS and Group Select the PFS check box, and select the DH2 (1024) key group.
Note: On the VPN firewall, this key group is referred to as Diffie-Hellman Group 2
(1024 bit).
