178 – Paper Jams
CX2731 MFP Basic User’s Guide
4 Touch any screw towards the front inside the machine to
remove static electricity from your body.
5 Hold the blue handles of the image drum unit (1) with both
hands and lift it out of the machine, then place it on a flat
surface.
WARNING!
If the machine has been turned on, the fuser unit (at the
back) may be hot. This area is clearly labelled. DO NOT
TOUCH IT.
CAUTION!
• The image drum unit is a static sensitive device and is
very delicate. Handle it carefully.
• Do not expose the image drum unit to direct sunlight or
very bright interior light (more than approximately 1500
lux).
• Even under the normal interior light, do not leave it for
more than 5 minutes.
To Next Page
