Oracle X8-2L Service Manual

Install a Flash Riser Board
Caution - If the riser board does not easily seat into the connector socket, verify that the notch
in the riser board is aligned with the connector key in the connector socket. If the notch is not
aligned, damage to the riser board might occur.
d.
Rotate the riser board socket levers inward until the riser board is secured
in place.
3.
(Optional) Repeat Step 2 to install a second flash riser board into the server.
4.
Return the server to operation.
a.
Install the server top cover.
See “Install the Server Top Cover” on page 218.
b.
Return the server to the normal rack position.
See “Return the Server to the Normal Rack Position” on page 220.
Related Information
■
“Remove a Flash Riser Board” on page 99
102 Oracle Server X8-2L Service Manual • January 2021
