Oracle X8-2L Service Manual

Front and Back Panel Components
Call
Out
Description
11 Storage drive 0 HDD/SSD/NVMe
12 Storage drive 1 HDD/SSD/NVMe
13 Storage drive 2 HDD/SSD/NVMe
14 Storage drive 3 HDD/SSD/NVMe
15 Storage drive 4 HDD/SSD/NVMe
16 Storage drive 5 HDD/SSD/NVMe
17 Storage drive 6 HDD/SSD/NVMe
18 Storage drive 7 HDD/SSD/NVMe
19 Storage drive 8 HDD/SSD/NVMe
20 Storage drive 9 HDD/SSD/NVMe
21 Storage drive 10 HDD/SSD/NVMe
22 Storage drive 11 HDD/SSD/NVMe
Related Information
■
“Troubleshooting Using the Server Front and Back Panel Status Indicators” on page 30
Back Panel Components and Cable Connections
Call
Out
Description
1 Power supply (PS 1)
18 Oracle Server X8-2L Service Manual • January 2021
