Oracle X8-2L Service Manual

Install the Disk Backplane
Install the Disk Backplane
1.
Lower the disk backplane into the server, and position it to engage the standoff
hooks [1 and 2].
2.
Lower the backplane bracket into the server, then using a Torx T25 screwdriver,
tighten the spring-mounted screws to secure the bracket to the chassis [3].
164 Oracle Server X8-2L Service Manual • January 2021
