Install the Server Top Cover
Filler Panel Type Removal Procedure Installation Procedure
Storage drive 1. Locate the storage drive filler panel to be removed
from the server.
2. To unlatch the storage drive filler panel, pull the
release lever, and then tilt the lever out into a fully
opened position.
3. To remove the filler panel from the slot, hold the
opened release lever, and gently slide the filler
panel toward you.
1. Locate the vacant storage drive module slot in the
server, and then ensure that the release lever on the
filler panel is fully opened.
2. Slide the filler panel into the vacant slot by pressing
the middle of the filler panel faceplate with your
thumb or finger.
3. The release lever will close as it makes contact with
the chassis. Do not slide the filler panel in all the
way. Leave the filler panel out approximately 0.25
to 0.50 inch (6 to 12 mm) from the opening.
4. Using your thumb or finger, press on the middle
of the filler panel faceplate until the release lever
engages with the chassis.
5. Close the release lever until it clicks into place and
is flush with the front of the server
PCIe slot 1. Remove the server top cover.
2. To remove the PCIe slot filler panel, rotate the PCIe
locking mechanism in to an upright position, and
then lift and remove the PCIe slot filler panel from
the location into which you intend to install the
PCIe card.
Note - In single-processor systems, PCIe slots 1
through 6 are nonfunctional; therefore, there is no need
to remove the filler panels for these slots.
1. Remove the server top cover.
2. To install the PCIe slot filler panel, press the PCIe
filler panel into the vacant PCIe slot, and then rotate
the PCIe locking mechanism downward to secure
the PCIe slot filler panel. You will hear an audible
click when the PCIe filler panel is secured into the
slot.
Note - In single-processor systems, PCIe slots 1
through 6 are nonfunctional; therefore, the server ships
with these filler panels installed.
Install the Server Top Cover
1.
Place the top cover on the chassis [1].
Set the cover down so that it hangs over the back of the server by about 1 inch (25 mm) and the
side latches align with the cutouts in the chassis.
2.
Check both sides of the chassis to ensure that the top cover is fully down and
flush with the chassis.
If the cover is not fully down and flush with the chassis, slide the cover towards the back of the
chassis to position the cover in the correct position.
3.
Gently slide the cover toward the front of the chassis until it latches into place
with an audible click [2].
As you slide the cover toward the front of the server, the release button on the top of the server
automatically rotates downward to the closed position. Latch the top cover by pushing down
218 Oracle Server X8-2L Service Manual • January 2021
