Oracle X8-2L Service Manual

Serial Management Port
TABLE 4
Network Management Port Signals
Pin
Signal Description Pin Signal Description
1 Transmit/Receive Data 0 + 5 Transmit/Receive Data 2 –
2 Transmit/Receive Data 0 – 6 Transmit/Receive Data 1 –
3 Transmit/Receive Data 1 + 7 Transmit/Receive Data 3 +
4 Transmit/Receive Data 2 + 8 Transmit/Receive Data 3 –
Related Information
■
“Back Panel Components and Cable Connections” on page 18
■
“Server System-Level Status Indicators” on page 31
■
“Disconnect Cables From the Server” on page 61
■
“Reconnect Power and Data Cables” on page 222
Serial Management Port
The serial management connector, labeled SER MGT, is an RJ-45 connector that can be
accessed from the back panel. This port is the default connection to the server Oracle ILOM SP.
Use this port only for server management.
TABLE 5
Default Serial Connections for Serial Port
Parameter Setting
Connector SER MGT
Rate 9600 baud
Parity None
Stop bits 1
Data bits 8
The following figure and table describe the SER MGT port pin signals.
Identifying the Server Ports 227
