Oracle X8-2L Service Manual

Assign Serial Port Output Using the Oracle ILOM Web Interface
Base MAC Address Corresponding Ethernet Port
“base” + 4 SP (NET MGT)
“base” + 5 Used only when Network Controller-Sideband Interface (NC-SI) sideband
management is configured.
Back Panel Pinhole Switches
Oracle Service personnel might instruct you to use the back panel pinhole switches to reset the
NMI, Host Warm Reset, or SP, as shown in the following figure.
Callout Icon Description
1 Non-maskable interrupt (NMI)
†
2 Host Warm Reset
3 SP Reset
†
Oracle Service use only.
46 Oracle Server X8-2L Service Manual • January 2021
