Oracle X8-2L Service Manual

Identify and Remove an M.2 Flash SSD
Identify and Remove an M.2 Flash SSD
In the standard Oracle Server X8-2L configuration, the flash riser board contains an M.2 flash
SSD in socket SSD0.
1.
Prepare the server for service.
a.
Extend the server into maintenance position.
See “Extend the Server to the Maintenance Position” on page 62.
b.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 65.
c.
Remove the server top cover.
See “Remove the Server Top Cover” on page 65.
2.
Identify and note the location of the failed M.2 flash SSD by pressing the Fault
Remind button on the motherboard.
See “Using the Server Fault Remind Button” on page 127.
Failed SSDs are identified with a corresponding amber LED that is lit on the flash riser board.
■
If the SSD fault LED is off, then the SSD is operating properly.
■
If the SSD fault LED is on (amber), then the SSD is failed and should be replaced [1].
Servicing the Internal M.2 Flash SSDs (CRU) 103
