Oracle X8-2L Service Manual

DIMM Operating Speeds
Population Order Processor/DIMM Slot
11. P1/D11
12. P1/D0
After black slots have been populated, populate white
slots in the following order:
1. P0/D6
2. P1/D6
3. P0/D5
4. P1/D5
5. P0/D8
6. P0/D3
7. P1/D8
8. P1/D3
9. P0/D10
10. P0/D1
11. P1/D10
12. P1/D01
DIMM Operating Speeds
The maximum supported memory speed is 2667 MT/s. However, not all system configurations
will support operation at this speed. The maximum attainable memory speed is limited by the
maximum speed supported by the specific type of processor. All memory installed in the system
operates at the same speed, or frequency.
DIMM Rank Classification Labels
DIMMs come in a variety of ranks: dual or quad. Each DIMM is shipped with a label
identifying its rank classification. The following table identifies the label corresponding to each
DIMM rank classification:
TABLE 1
DIMM Rank Classification Labels
Rank Classification Label
Quad-rank LRDIMM 4Rx4
Dual-rank RDIMM 2Rx4
126 Oracle Server X8-2L Service Manual • January 2021
