Oracle X8-2L Service Manual

Identifying the Server Ports
These sections describe the pinouts of the server connectors:
■
“Gigabit Ethernet Port” on page 225
■
“Network Management Port” on page 226
■
“Serial Management Port” on page 227
■
“USB Ports” on page 229
Related Information
■
“About the Oracle Server X8-2L” on page 15
Gigabit Ethernet Port
The server has one auto-negotiating 100/1000BASE-T Gigabit Ethernet (GbE) system domain
port that uses a standard RJ-45 connector. The transfer rates are shown in the following table.
TABLE 2
Ethernet Port Transfer Rates
Connection Type IEEE Terminology Transfer Rate
Fast Ethernet 100BASE-T 100 Mbps
Gigabit Ethernet 1000BASE-T 1,000 Mbps
The following figure and table describe the GbE port pin signals.
Identifying the Server Ports 225
