Servicing the Internal M.2 Flash SSDs (CRU)
This section describes how to service M.2 flash solid-state drives (SSDs). M.2 flash SSDs
are customer-replaceable units (CRUs) that do not require you to power off the server. For
more information about CRUs, see “Illustrated Parts Breakdown” on page 20 and “Customer-
Replaceable Units” on page 21.
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the component to fail. To avoid damage,
ensure that you follow antistatic practices as described in “Electrostatic Discharge
Safety” on page 52.
This section covers the following procedures:
■
“Remove a Flash Riser Board” on page 99
■
“Install a Flash Riser Board” on page 101
■
“Identify and Remove an M.2 Flash SSD” on page 103
■
“Install an M.2 Flash SSD” on page 105
Related Information
■
“Servicing Storage Drives (CRU)” on page 69
Remove a Flash Riser Board
The server can contain up to two hot-pluggable flash riser boards. Each flash riser board can
contain either one or two M.2 flash SSDs.
1.
Prepare the server for service.
a.
Extend the server into maintenance position.
See “Extend the Server to the Maintenance Position” on page 62.
Servicing the Internal M.2 Flash SSDs (CRU) 99
