Monitoring System Components
■
“Memory Device Components” on page 295
■
“Power Unit Components” on page 295
■
“Processor Components” on page 297
■
“System Motherboard Components” on page 297
■
“System Firmware Components” on page 299
■
“Hard Disk Drive Components” on page 299
Cooling Unit Components
The system has four 80-mm fan modules with two fans in each module. The following table
lists the system cooling unit components.
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/FM[0-3] FRU Fan module FRU
/SYS/MB/FM[0-3]/F[0-x] FRU Individual fan
/SYS/MB/FM[0-3]/PRSNT Discrete sensor Fan module is present. 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/FM[0-3]/F[0-x]/TACH Threshold sensor Fan module fan speed RPM
/SYS/MB/FM[0-3]/SERVICE Indicator Fan Fault-Service Required LED Color: Amber
Location: Motherboard
Off: Normal
On: Fan module was diagnosed as
faulty.
Related Information
■
“System Chassis Components” on page 291
■
“Disk Backplane Components” on page 294
■
“Memory Device Components” on page 295
■
“Power Unit Components” on page 295
■
“Processor Components” on page 297
■
“System Motherboard Components” on page 297
■
“System Firmware Components” on page 299
■
“Hard Disk Drive Components” on page 299
Monitoring Components and Identifying SNMP Messages 293
