Monitoring System Components
Component Name (Oracle
ILOM CLI Targets)
IPMI Type Description Values (if applicable)
Off: Power is off.
Standby blink: Standby power is on; Oracle
ILOM SP is running.
Slow blink: Startup sequence initiated on
host.
On: Host is booting OS or running the OS.
/SYS/SERVICE Indicator Fault-Service Required LED Color: Amber
Location: Front and back panels
Off: Normal
On: Server requires service.
/SYS/LOCATE Indicator Locate Button/LED Color: White
Location: Front and back panels
Off: Normal
Fast blink: Locate function is activated;
self-extinguishes after 30 minutes.
/SYS/PS_FAULT Indicator Rear Power Supply Fault LED Color: Amber
Location: Front panel
Off: Normal
On: General power supply fault
/SYS/FAN_FAULT Indicator Top Fan Fault LED Color: Amber
Location: Front panel
Off: Normal
On: General fan fault
/SYS/DO_NOT_SERVICE Indicator Do Not Service LED Color: White
Location: Front panel
Off: Normal
On: Do not service
Related Information
■
“Cooling Unit Components” on page 293
■
“Disk Backplane Components” on page 294
292 Oracle Server X8-2L Service Manual • January 2021
