Servicing PCIe Cards (CRU)
This section describes how to service PCIe cards. PCIe cards are customer-replaceable units
(CRUs) that require you to power off the server. For more information about CRUs, see
“Illustrated Parts Breakdown” on page 20 and “Customer-Replaceable Units” on page 21.
Refer to your PCIe card documentation for complete software and cabling information about
your card.
Caution - Customers should not use the procedures in this section to service the Oracle Storage
12 Gb SAS PCIe RAID HBA, Internal card that is located in PCIe slot 11 or the Oracle PCIe
NVMe switch cards that are located in PCIe slots 3, 4, 8, and 9. The Oracle Storage 12 Gb SAS
PCIe RAID HBA, Internal card and Oracle PCIe NVMe switch cards are field-replaceable units
(FRUs) and should be serviced only by authorized Oracle Service personnel.
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Electrostatic Discharge
Safety” on page 52.
Caution - Ensure that all power is removed from the server before removing or installing
PCIe cards. You must disconnect all power cables from the system before performing these
procedures.
Note - For a complete list of supported PCIe cards, refer to the Oracle Server X8-2L Product
Notes at https://www.oracle.com/goto/x8-2l/docs.
This section covers the following topics and procedures:
■
“PCIe Slot Locations” on page 134
■
“Remove a PCIe Card” on page 135
■
“Install a PCIe Card” on page 137
Servicing PCIe Cards (CRU) 133
