Install the Internal HBA Card and HBA Super Capacitor
Related Information
■
“Install the Internal HBA Card and HBA Super Capacitor” on page 185
Install the Internal HBA Card and HBA Super Capacitor
1.
Unpack the replacement internal HBA card and super capacitor, and place them
on an antistatic mat.
2.
Insert the internal HBA card into PCIe slot 11, and rotate the PCIe locking
mechanism to secure the PCIe HBA card in place [1 and 2].
Servicing the Internal HBA Card (FRU) and HBA Super Capacitor (CRU) 185
