About System Components
Call
Out
Description
2 Power Supply (PS) 1 status indicators: Fault-Service Required LED: amber; AC OK LED: green
3 Power supply (PS 0)
4 Power Supply (PS) 0 status indicators: Fault-Service Required LED: amber; AC OK LED: green
5 PCIe slot 1 (Nonfunctional in single-processor systems)
6 PCIe slot 2 (Nonfunctional in single-processor systems)
7 PCIe slot 3 (Nonfunctional in single-processor systems)
8 PCIe slot 4 (Nonfunctional in single-processor systems)
9 PCIe slot 5 (Nonfunctional in single-processor systems)
10 PCIe slot 6
11 Serial management (SER MGT) RJ-45 serial port
12 Oracle Integrated Lights Out Manager (ILOM) service processor (SP) network management (NET MGT)
RJ-45 10/100/1000BASE-T port
13 Network (NET) 10/100/1000BASE-T RJ-45 Gigabit Ethernet (GbE) port: NET 0
14 USB 3.0 connector
15 System status LEDs: Locate Button/LED: white; Fault-Service Required: amber; System OK: green
16 PCIe slot 7
17 PCIe slot 8
18 PCIe slot 9
19 PCIe slot 10
20 PCIe slot 11
Note - For more information on back panel components and connections, see “Back Panel
Connector Locations” on page 41. See also “Back Panel Pinhole Switches” on page 46.
Related Information
■
“Troubleshooting Using the Server Front and Back Panel Status Indicators” on page 30
■
“Disconnect Cables From the Server” on page 61
■
“Reconnect Power and Data Cables” on page 222
■
“Identifying the Server Ports” on page 225
About System Components
These sections describe the components of the server:
About the Oracle Server X8-2L 19
