Remove the Air Baffle
See “Extend the Server to the Maintenance Position” on page 62.
c.
Attach an antistatic wrist strap to your wrist and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 65.
d.
Remove the server top cover.
See “Remove the Server Top Cover” on page 65.
2.
Release the latch for the host bus adapter (HBA) super capacitor tray and rotate
the tray [1] in to the upright position [2].
114 Oracle Server X8-2L Service Manual • January 2021
