Remove the Front LED Indicator Module
Note - You might need to disconnect the SAS cable connections from the Oracle Storage 12
Gb SAS PCIe RAID HBA, Internal card in PCIe slot 11 to access the LED indicator module
motherboard cable connection. To ease removal of the LED indicator module cable, slightly lift
the SAS cable bundles from the cable trough along the left side of the chassis. See “Servicing
SAS Cables (FRU)” on page 189.
Servicing the Front LED Indicator Module (FRU) 169
