Oracle X8-2L Service Manual

Install NVMe Cables
Plug each cable into its NVMe connector until you hear an audible click.
Use the following table to ensure proper NVMe cable connections.
Oracle PCIe NVMe
Slot Location and
Cable Part Number
HBA Connector Disk Backplane
Connector
Physical Storage
Drive Slots
1 D 2
2 E 6
3 (7345518)
3 F 10
1 A 3
2 B 7
4 (7345517)
3 C 11
1 A 1
2 B 5
8 (7345517)
3 C 9
1 D 0
2 E 4
9 (7345518)
3 F 8
4.
Return the server to operation.
a.
Install the fan tray.
See “Install the Fan Tray” on page 90.
b.
Install the fan modules.
See “Install a Fan Module” on page 87.
c.
Install the air baffle.
See “Install the Air Baffle” on page 115.
d.
Install the server top cover.
See “Install the Server Top Cover” on page 218.
e.
Return the server to the normal rack position.
See “Return the Server to the Normal Rack Position” on page 220.
f.
Reconnect the power cords to the power supplies, and power on the server.
Servicing NVMe Cables (FRU) 199
