Install the Motherboard Assembly
■
Power supplies
See “Install a Power Supply” on page 96.
■
PCIe cards
See “Install a PCIe Card” on page 137.
■
NVMe cables (if present)
See “Install NVMe Cables” on page 198.
■
SAS storage drive cables (if present)
See “Install SAS Storage Drive Cables” on page 192.
■
Fan tray
See “Install the Fan Tray” on page 90.
■
Fan modules
See “Install a Fan Module” on page 87.
■
Air baffle
See “Install the Air Baffle” on page 115.
6.
If present, install the Oracle Storage 12 Gb SAS PCIe RAID HBA, Internal card
and its associated super capacitor.
See “Install the Internal HBA Card and HBA Super Capacitor” on page 185.
Note - Before you install the HBA super capacitor, install the HBA super capacitor tray by
squeezing the plastic hinges together and inserting the tray into the chassis.
7.
Return the server to operation.
a.
Install the server top cover.
See “Install the Server Top Cover” on page 218.
b.
Return the server to the normal rack position.
See “Return the Server to the Normal Rack Position” on page 220.
c.
Reconnect the power cords to the power supplies, and power on the server.
See “Reconnect Power and Data Cables” on page 222 and “Power On the
Server” on page 222.
d.
Verify that the power supply AC OK LED is lit.
Servicing the Motherboard Assembly (FRU) 215
