Oracle X8-2L Service Manual

Monitoring System Components
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/NET[0-x] FRU Host Ethernet FRU
/SYS/MB/PCIE[1-x] FRU PCIe slot
/SYS/MB/PCIE[1-x]/PRSNT Discrete sensor PCIe slot is occupied. 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/PCIE[1-x]/PCIESW FRU PCIe switch for NVMe support
/SYS/MB/PCIE[1-x]/PCIESW/PRSNT Discrete sensor PCIe switch for NVMe support is
installed in this PCIe slot.
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/T_OUT_ZONE[0-2] Threshold sensor Cooling zone output temperature
sensor
Degrees Celsius
/SYS/MB/T_IN_ZONE[0-2] Threshold sensor Cooling zone input temperature
sensor
Degrees Celsius
/SYS/SP FRU Service processor FRU
/SYS/SP/OK Indicator SP OK LED Color: Green
Location: Front panel
On: SP is operating.
Off: SP requires service.
/SYS/SP/NET[0-1] FRU SP Ethernet FRU
/SYS/MB/M2R[0-1]/ FRU M.2 SSD riser
/SYS/MB/M2R[0-1]/SSD0 FRU Internal M.2 SSD drives
/SYS/MB/M2R[0-1]/PRSNT Discrete sensor M.2 riser presence 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/M2R[0-1]/SSD0/PRSNT Discrete sensor M.2 SSD drive presence 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/M2R[0-1]/SSD0/STATE State sensor M.2 SSD drive state sensor 04h-INSTALLED
20h-SLOT_POWER_OFF
/SYS/MB/M2R[0-1]/SSD0/NVME FRU Internal M.2 SSD is NVMe
/SYS/MB/M2R[0-1]/SSD0/NVME/
PRSNT
Discrete sensor Indicates the M.2 SSD is PCIe
(NVMe).
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Related Information
■
“System Chassis Components” on page 291
■
“Cooling Unit Components” on page 293
■
“Disk Backplane Components” on page 294
