Remove a Storage Drive
4.
Push the latch release button to open the drive latch [1, 2].
Callout Description
1 Pressing the latch release button.
2 Opening the latch.
Caution - The latch is not an ejector. Do not open the latch too far to the right. Doing so can
damage the latch.
Servicing Storage Drives (CRU) 73
