C H A P T E R
95
7
Using Pipeline Control
Pipeline Control is a client application for controlling capture and play out from Pipeline devices. The Mac
OS X version supports log and capture, scheduled capture, and scheduled play out. The Windows version
supports scheduled capture only. Both application support SD and HD Pipeline devices – Pipeline SC,
Pipeline Quad, and Pipeline HD Dual. The user interface is similar on both platforms, but there are minor
differences.
Use this chapter to learn how to use the general features Pipeline Control. For details on scheduled
playout and capture, see Chapter 8, Using Scheduled Playout & Capture (page 125). For details on
realtime log and capture, see Chapter 9, Using Pipeline Control (page 95).
Topics
Opening Pipeline Control (page 96)
Pipeline Control Overview (page 97)
Pipeline Control Menus (page 99)
The Pipeline Settings Toolbar (page 102)
Configuring Publishers (page 107)
The Preview Panel (page 116)
Preferences – Mac OS X (page 119)
Preferences – Windows (page 122)
Using the Diagnostics Panel (page 124)
When there are differences in how you perform a task on Mac OS X and Windows, instructions are
presented as illustrated in this example:
Click Start > All Programs > Telestream > Pipeline.
In the Finder, double-click the Pipeline Control icon in the Applications folder.
Note
Pipeline Control can only be used with Pipelines whose firmware is compatible.
When you install or upgrade Pipeline software, you may need to upgrade your Pipeline
firmware as well. If you select a Pipeline with older firmware, you will be warned that
this may cause problems.
